| 3 - User manual
To install a MADI Card in the Base Station:
Completely disconnect the Base Station from the power supply system. See
Connecting/disconnecting the Base Station to/from the power supply system.
Unscrew one of the dummy caps on the Base Station. To do so, you require a torx® 10
screwdriver.
Fully slide the MADI Card into the open slot as shown in the figure.
The card can be inserted into the Base Station housing only in one direction.
The lettering on the card must face upward.
31
