| 3 - User manual
Meaning of the LED
The LED on top and below indicates the same information.
The LED is off:
• The antenna is not connected to the Base Station.
The LED is flashing green:
• The antenna is connecting to the Base Station.
The LED is green:
• The antenna is connected to the Base Station and one
or both RF channels are active.
The LED is yellow:
• The antenna is connected to the Base Station and one
or both RF channels are muted.
The LED is flashing white:
• The connected antenna is identified.
The LED is flashing green and red:
• Firmware update is in progress.
99
