| 3 - User manual
Connecting word clock
You can use the internal word clock on the Base Station or connect an external word clock.
You can also output the external word clock and cascade it up to 8 Base Stations.
The word clock output transmits only the external word clock that is connected via the word
clock input. The internal word clock is not output via the word clock output.
For more information about the word clock, see Word clock scenarios for digital
audio.
To connect an external word clock:
Use a coaxial BNC cable (75 Ω) to connect the external word clock to the word clock
in input.
39
