| 3 - User manual
DAD
Product overview
Information on antenna setup
Meaning of the LED
Placing on a stand
Connecting/disconnecting the antenna
Antenna cable extension
Updating the DAD
Product overview
1 LED to indicate the status
• see Meaning of the LED
2 Hole for rigging safety cable
3 Ruggedized RJ45
• see Connecting/disconnecting the antenna
4 Microphone stand
• see Information on antenna setup
96
