| 3 - User manual
The headphone volume displays for five seconds.
The volume can be altered between -100 dB to +27.5 dB in steps
of 0.5 dB.
Turn the rotary encoder slowly to change the volume.
The volume changes by 0.5 dB per click.
Turn the rotary encoder quick to change the volume.
The volume changes dynamically in larger increments.
To display the mic/line level:
Only available if mic audio link is activated.
Press the rotary encoder.
The backlight is on for five seconds.
Press the rotary encoder again within 5 seconds after the first press.
The mic/line level is displayed. The five LEDs show the input level.
To display the E-label:
The SEK is paired to the Base Station and the activated license uses E-lables.
Press the rotary encoder.
The backlight is on for five seconds.
Press the rotary encoder till the end of the menu.
Press the rotary encoder long for E-label screen.
The first page of the E-label displays.
Press the rotary encoder again to display subsequent E-labels.
92
