98 DF-310E Troubleshooting and Calibration
3) If it is not practical to remove the Analyzer from the sample delivery system, leaks can be
located by monitoring Analyzer output while applying Snoop® or another liquid leak detector to
one fitting at a time. Snoop® will not show bubbles at the low pressure required for proper
Analyzer operation. However, Snoop® will temporarily block any leak, at the fitting being
checked, and the Analyzer output will drop. It is important to give sufficient time for the
Analyzer to respond before going on to the next fitting.
The more distance between the fitting and the Analyzer, the more time should be given for the
Analyzer to respond.
9.4.2 Basic Troubleshooting
Solutions are listed in the order that they should be attempted.
POSSIBLE
PROBLEMS SOLUTIONS
1) Analyzer reads low A B D E H I J Z
2) Analyzer reads high A B C D E I J Z
3) Analyzer output is noisy A E I Z
4) Analyzer reads high with pump on C Z
5) Analyzer reads 0.00 at all times Q D Z
6) Slow speed of response G C D E Z
7) Electrolyte residue (white powdery build-up) visible Z
on the sensor
8) Electrolyte Condition alarm “ON” P D E Z
9) Display is blank, or shows an unusual appearance K O Z
10) Display reads any of the following:
- Over Range or TEMP OVER RANGE L M N Z
- NOVRAM Failure Z
- Uncalibrated Z
11) Span reading is unacceptably high (>50% high) R C J Z
12) Span reading is unacceptably low (>50% low) R J E Z
