Servomex DF-310E User Manual

Options DF-310E 27
9.26 [235.08]
7.89 [200.48]
7.75 [196.75]
8.33 [211.48]
7.59 [192.79]
4.21 [106.93]
2.05 [52.07]
6.50 [165.13]
2.04 [51.82]
4.63 [117.60]
8.71 [221.23]
.30 [7.62] 9.36 [237.87]
9.97 [253.11]
Ø.22 [Ø5.59]
4 PL
1.17 [29.77]
P
P
M
Figure 11: Panel Mount Configuration
8.95 [227.33]
9.37 [237.87]
.21 [5.27]
1.91 [48.39]
4.63 [117.60] 8.44 [214.38]
Ø.22 [Ø5.59]
4 PL
Figure 12: Cutout Dimensions for Panel Mount
