Servomex SERVOPRO FID User Manual

SERVOPRO FID Online Total Hydrocarbons Analyser
SERVOPRO FID 01000001A rev:5 17
2.11 Fuel shut-off/Hydrogen relay output
Total maximum current
1 Amp
Connector type
Terminal block
Maximum voltage
24 VDC
Cable requirements
Type
Maximum size
Multi-core cable with overall screen
0.82 mm
2
(18 AWG)
Table 12 : Hydrogen output specifications
2.12 Ethernet connector
Cable requirements
Standard
Connector type
Maximum length
10 BaseT
RJ45 (CAT5 UTP)
30 m
Table 13 : Ethernet connector
2.13 RS-232 Connector
Type
Male 9 way D connector
Cable requirements
NULL modem
Shielded cable
Maximum length
30 m
Table 14 : RS-232 Connector
