Servomex SERVOPRO FID User Manual

SERVOPRO FID Online Total Hydrocarbons Analyser
SERVOPRO FID 01000001A rev:5 57
Data
Details
Impurity
Impurity value with two digits after the dot.
Tab
ASCII character 11.
Air flow
Air flow value with two digits after the dot.
Tab
ASCII character 11.
Fuel flow
Fuel flow value with two digits after the dot.
Tab
ASCII character 11.
Sample flow
Sample flow value with two digits after the dot.
Tab
ASCII character 11.
Detector numerical value
Detector numerical value in counts.
Tab
ASCII character 11.
FID Temperature
FID temperature in Celsius with two digits after
the dot.
Tab
ASCII character 11.
Reserved
Tab
ASCII character 11.
Reserved
Tab
ASCII character 11.
Status
The status of analyser is given on a single byte.
This is a bitwise information.
Bit
Description
State
7
Alarm 2
1 if alarm 2 ON
0 if alarm 2 OFF
6
Alarm 1
1 if alarm 1 ON
0 if alarm 1 OFF
5
Status
1 if status ON
0 if status OFF
4
Flame
1 if flame ON
0 if flame OFF
3-1
Range
001 = range 1
010 = range 2
100 = range 3
0
Reserved
Always 0
Tab
ASCII character 11.
Checksum
CRC16 checksum. Be aware that TAB characters
are not part of the CRC16 checksum.
Carriage return
ASCII 13.
New line
ASCII 10.
Table 21 : RS-232 protocol description
Note: The checksum is calculated with the decimal value of ASCII character.
