SERVOPRO FID Online Total Hydrocarbons Analyser
SERVOPRO FID 01000001A rev:5 27
Figure 12 – Temp diagnostic
Figure 13 – System diagnostic
Figure 14 – System diagnostic
Figure 15 – Alarm historic
Parameter
Unit
Range
Description
Air flow
cc/min
0-1000
Actual air flow.
Air pressure
PSI
0-100
Actual air pressure.
Air counts
Counts
0-65535
Actual air sensor signal.
Air output
%
0-100
Actual air pressure regulator control
output.
Fuel flow
cc/min
0-200
Actual fuel flow.
Fuel pressure
PSI
0-100
Actual fuel pressure.
Fuel counts
Counts
0-65535
Actual fuel sensor signal.
Fuel output
%
0-100
Actual fuel pressure regulator.
PRV|00)01/01/2009 Smp Dev 19:12:45
<
--|01)01/01/2009 Flame Off 19:12:42
NXR|02)01/01/2009 Fuel Low 19:
12:41
-->|03)01/01/2009 Air Low 19:12:25
<-- <<<<SYSTEM DIAGNOSTIC>>>>
Serial Number: 10000
www.servomex.com info@servomex.com
<-- <<<SYSTEM DIAGNOSTIC>>> -->
UI v1.90.5 IO Board v1.83.5
Reg. Smp v9.53 Air v9.53 Fuel v9.53
Last maintenance: 01/01/2009
<-- <<<TEMP DIAGNOSTIC>>>
FID: 100.0C 912544 Counts 35.1%
