SERVOPRO FID Online Total Hydrocarbons Analyser

SERVOPRO FID 01000001A rev:5 41

5.2 Mechanical installation

SERVOPRO FID analyser must be installed as shown in picture 36 and 37. Two

brackets are necessary, one to support the front and one to support the back of the

analyser.

Figure 36 – Front bracket assembly

Figure 37 – Rear braket assembly

WARNING

Improper installation, operation or service of this analyser may

cause damage to the analyser and void the manufacturer’s

warranty.
