4.6 Diagnostic
This menu is very useful for troubleshooting. This menu groups many sensor
signals like pressures, temperatures and detector signal. All parameters are
explained in table 8.
Figure 9 - Diagnostic menu
Figure 10 – Signal diagnostic
Figure 11 – Flow diagnostic
<-- <<<SIGNAL DIAGNOSTIC>>>
Chrom signal: 0.9542 V
rom counts: 3201763 Counts
<-- <<DIAGNOSTIC MENU>>
1) Signal diag.
2) Flow diag. 5) System info.
3) Temperature diag. 6) Alarm historic
<-- <<<FLOW DIAGNOSTIC>>>
Smp: 30 CC 2.5 PSI 7714 Cnts 0.0 %
Air:
300 CC 72.5PSI 45658 Cnts 66.1 %
Fuel: 100 CC 68.1PSI 32587 Cnts 52.1 %
To Next Page
