Shark MP200 - Page 463

Doc# E166703 E-11
E: Retrieving Logs
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Electro Industries/GaugeTech
The Leader In Power Monitoring and Smart Grid Solutions
Log Retrieval Header:
The Log Retrieval Header is used to program the log to be retrieved, the record(s) of
that log to be accessed, and other settings concerning the log retrieval.
Registers: 0xC34F - 0xC350
Size: 2 registers
• Log Number: The log to be retrieved. Write this value to set which log is being
retrieved.
0 System Events
1 Historical Log 1
2 Historical Log 2
3 Historical Log 3
4 Alarm Log
5 I/O Change Log
Bytes Value Type Format Description # Bytes
0-1 Log Number,
Enable,
Scope
UINT16 nnnnnnnn esssssss nnnnnnnn -
log to
retrieve,
e - retrieval
session
enable
sssssss -
retrieval
mode
2
2-3 Records per
Window,
Number of
Repeats
UINT16 wwwwwwww nnnnnnnn wwwww-
www -
records per
window,
nnnnnnnn -
repeat count
2
