MX-M316N SIMULATION 6 – 23
24-4
Purpose
Data clear
Function (Purpose)
Used to clear the maintenance counter, the
printer counters of the transport unit and
the fusing unit. (After completion of mainte-
nance, clear the counters.)
Section
Operation/Procedure
1) Select the item to be cleared with the touch panel key.
2) Press [EXECUTE] key.
3) Press [YES] key.
The target counter is cleared.
24-5
Purpose
Data clear
Function (Purpose)
Used to clear the developer counter. (After
replacement of developer, clear the coun-
ter.)
Section
Operation/Procedure
1) Select the item to be cleared with the touch panel key.
2) Press [EXECUTE] key.
3) Press [YES] key.
The target counter is cleared.
NOTE: The "Developer cartridge life meter" counter displayed in
SIM22-13 is not displayed in this simulation, but it is
cleared in conjunction with this simulation.
24-6
Purpose
Data clear
Function (Purpose)
Used to clear the copy counter.
Section
Operation/Procedure
1) Select the item to be cleared with the touch panel key.
2) Press [EXECUTE] key.
3) Press [YES] key.
The target counter is cleared.
24-9
Purpose
Data clear
Function (Purpose)
Used clear the printer mode print counter
and the self print mode print counter.
Section
Operation/Procedure
1) Select the item to be cleared with the touch panel key.
2) Press [EXECUTE] key.
3) Press [YES] key.
The target counter is cleared.
24-10
Purpose
Data clear
Function (Purpose)
Used to clear the FAX counter.
(Only when FAX is installed)
Section
Operation/Procedure
1) Select the item to be cleared with the touch panel key.
2) Press [EXECUTE] key.
3) Press [YES] key.
The target counter is cleared.
Item/Display Content
Maintenance MAINTENANCE
ALL
Maintenance counter (Total) (Counter)
Maintenance counter (Total)
(Number of use days)
Fusing FUSING
ROLLER
Fusing roller (Counter)
Fusing roller (Number of use days)
Fusing roller
(Accumulated number of rotations)
PRESS
ROLLER
Pressure roller (Counter)
Pressure roller (Number of use days)
Pressure roller
(Accumulated number of rotations)
Separation SEPARATE
PAWL(U)
Upper separation pawl (Counter)
Upper separation pawl (Number of use
days)
Upper separation pawl
(Accumulated traveling distance)
CLEAN FELT Clean felt (Counter)
Clean felt (Number of use days)
Clean felt
(Accumulated number of rotations)
Transfer TC UNIT Transfer unit (Counter)
Transfer unit (Number of use days)
Transfer unit
(Accumulated number of rotations)
Drum DRUM CTRG K Drum cartridge (K) (Counter)
Drum cartridge (K) (Number of use
days)
Drum cartridge (K) (Accumulated
traveling distance)
Main
charger
MAIN
CHARGER K
Main charger (K) (Counter)
Main charger (K) (Number of use days)
Main charger (K) (Accumulated
traveling distance)
Drum blade DRUM BLADE
K
Drum blade K (Counter)
Drum blade K (Number of use days)
Drum blade K (Accumulated traveling
distance)
Other OZONE FILTER Ozone filter (Counter)
Ozone filter (Number of use days)
K
Developer cartridge print counter (K)
Developer cartridge accumulated traveling distance (cm) (K)
Number of day that used developer (Day) K
COPY BW Copy counter (B/W)
PRINT BW Print counter (B/W)
OTHER BW Other counter (B/W)
FAX OUTPUT FAX Print quantity counter
FAX SEND FAX send counter
FAX RECEIVED FAX receive counter
SEND IMAGES FAX send quantity counter
SEND TIME FAX send time
RECEIVED TIME FAX receive time
