Sharp MX-M266N

MX-M316N TROUBLESHOOTING 7 – 5
F. Error code list
Trouble
code
Trouble content
Trouble
detection
Mechanism Option Electricity FAX Supply
Main
code
Sub
code
A0 01 PCU PWB ROM error MFP O
02 SCU PWB ROM error MFP O
11 Firmware version inconsistency (MFP - PCU) MFP O
15 Incompatible DSK BOOT and program firmware MFP O
20 Conflict firmware and EEPROM data version (MFP) MFP O
21 Conflict firmware and EEPROM data version (PCU) PCU O
22 Conflict firmware and EEPROM data version (SCU) SCU O
E7 01 MFP image data error MFP O
03 HDD trouble MFP O
04 HDD-ASIC error MFP O
07 SD card error MFP O
10 Shading error (Black correction) SCU O
11 Shading error (White correction) SCU O
14 CCD-ASIC error SCU O
20 LSU laser detection error PCU O
21 LSU LD deterioration trouble PCU O
28 LSU control Asic connection error PCU O
49 Water Mark data error MFP O
50 PCU connection trouble PCU O
60 MFP connection trouble MFP O
61 MFP connection trouble (PCU) MFP O
62 MFP connection trouble (SCU) MFP O
80 MFP - SCU PWB communication error MFP O
90 MFP - PCU PWB communication error MFP O
91 FAX reception image data error MFP O
92 Copy image data error MFP O
93 Copy, image send, FAX, filing, print image data process error MFP O
94 Image file data process error (when importing file data) MFP O
96 MFPC PWB DIMM memory check error MFP O
EE EL Auto developer adjustment trouble (Over-toner abnormality) PCU O
EU Auto developer adjustment trouble (Under-toner abnormality) PCU O
F1 00 Finisher - PCU PWB communication error PCU O
03 Finisher paper exit roller lifting operation trouble PCU O
10 Staple operation trouble PCU O
15 Finisher paper exit tray lift operation trouble PCU O
19 Finisher alignment operation trouble F PCU O
20 Finisher alignment operation trouble R PCU O
29 Finisher cooling fan motor abnormality MFP O
37 Finisher data backup RAM error PCU O
50 Main unit - Finisher combination error PCU O
95 Paper exit option configuration error PCU O
F2 39 Process thermistor trouble PCU O
40 Toner density sensor trouble PCU O
58 Temperature/humidity sensor trouble (HUD_M/TH_M) PCU O
64 Toner supply operation trouble PCU O
70 Improper toner cartridge detection PCU O
74 Toner cartridge CRUM error PCU O
F3 12 Paper feed tray 1 lift operation trouble PCU O
22 Paper feed tray 2 lift operation trouble PCU O
32 Paper feed tray 3 lift operation trouble
42 Paper feed tray 4 lift operation trouble
F6 00 MFPC PWB - FAX communication trouble MFP O
01 FAX control PWB EEPROM read/write error FAX O
04 FAX MODEM operation trouble FAX O
21 Improper combination of TEL/LIU PWB and FAX soft switch MFP O
30 FAX 1-chip microprocessor access error (FAX detection) MFP O
97 Incompatibility between FAX control PWB and the main machine MFP O
98 Incompatibility between the FAX control PWB destination and the main
machine destination
MFP O
H2 00 Thermistor open trouble (TH_UM) PCU O
01 Thermistor open trouble (TH_US) PCU O
H3 00 Fusing section high temperature trouble (TH_UM) PCU O
01 Fusing section high temperature trouble (TH_US) PCU O
H4 00 Fusing section low temperature trouble (TH_UM) PCU O
01 Fusing section low temperature trouble (TH_US) PCU O
H5 01 5-time continuous jams of POSD PCU O
L1 00 Scanner feed trouble SCU O
