MX-M316N SPECIFICATIONS 2 – 12
7. Dimensions and weight
MX-316N/ MX-M266N/ MX-M315N/ MX-M315U/
MX-M356N/ MX-M356U
MX-M265N/ MX-M265U
Outer dimension
(Included operation panel)
W620 x D617 x H680 mm
When the OC is installed:
W620 x D617 x H700 mm
When the RSPF is installed:
W620 x D617 x H830 mm
W620 x D617 x H580 mm
When the OC is installed:
W620 x D617 x H600 mm
When the RSPF is installed:
W620 x D617 x H730 mm
Footprint W620 x D617 mm
Dimension occupied by the machine W938 x D617 mm
(when the bypass tray is extended)
Weight
Main Unit
(including photoreceptor / not including
consumables)
When the RSPF is installed:
51 kg (100V type / 200V type)
When the OC is installed: 45 kg
When the RSPF is installed:
45 kg (100V type / 200V type)
When the OC is installed: 39 kg
