Sharp MX-M266N Service Manual

MX-M316N SPECIFICATIONS 2 – 1
MX-M316N
Service Manual
[2] SPECIFICATIONS
1. Basic specifications
A. Engine Specification
B. Engine speed (ppm)
Tray 1 - 4
Manual paper feed
C. Printable area
D. Engine resolution
*: The dither and error diffusion methods using 8bit input will be
performed.
E. Scanner section
(1) Resolution/Gradation
(2) Document table
Photo conductor OPC (Diameter: 30mm)
Recording Electronic photo (Laser)
Development Dry-type dual-component magnetic
brush development
Charging Charged saw-tooth method
Transfer Transfer roller
Separation Separation claw method
Cleaning Counter blade
Fusing Heat roller
Waste toner disposal Toner cartridge collection
Toner supply during operation N/A
Outer color Pastel white (Natural wave pattern)
Paper size
26cpm
machine
31cpm
machine
35cpm
machine
A3 15 17
20
11x17 14 17
19
8K 16 19
21
B4, 8.5x13, 8.5x13.5, 8.5x13.4, 8.5x14 16 20
22
A4, B5, 8.5x11, 16K, A5R, 5.5x8.5R 26 31
35
A4R, 8.5x11R, 16KR 18 24
27
B5R 21 24
30
Paper size
26cpm
machine
31cpm
machine
35cpm
machine
A3 14 17
18
11x17 14 16
17
8K 15 18
19
B4, 8.5x14 16 19
20
8.5x13 17 20
22
8.5x13.5, 8.5x13.4 16 19
21
A4, B5, 8.5x11, 16K, A5R, 5.5x8.5R,
A5, 5.5x8.5
23 27 29
A4R, 8.5x11R, 7.25x10.5R 19 22 24
16KR 19 22 25
B5R 21 24
26
Extra 14 16
17
Custom 14 16
17
A3 Wide N/A 16K 191 x 263mm
A3 293 x 413mm 12 x 18 N/A
B4 253 x 357mm 11" x 17" 275 x 425mm
A4 206 x 290mm 8.5" x 14" 212 x 349mm
B5 178 x 250mm 8.5" x 13" 212 x 323mm
A5 144 x 203mm Executive 180 x 260mm
Postcard 92 x 140mm 8.5" x 11" 212 x 272mm
8K 266 x 383mm 5.5" x 8.5" 136 x 209mm
8.5x13.5 212 x 336mm 8.5" x 13.4" 212 x 333mm
Custom Min.: 96mm x 141mm; Max.: 297mm x 432mm
Max. range AB: 416x293mm (600dpi: 9826dot x 6920dot)
Inch: 428x275mm (600dpi: 10110dot x 6496dot)
Void Area Top 1 to 4mm
Bottom 1 to 5mm
Front/Rear Total 6mm or less
Image Loss Top 4mm or less
Front/Rear Total 6mm or less
Image missing
width
Top 4mm or less, Bottom 4mm or less,
Front/Rear Total 6mm or less
Resolution Copy Writing
600 x 600dpi
Print Writing
600 x 600dpi
1,200 x 600dpi (PCL/PS)
Gradation *
(256 levels)
Copy Writing
600 x 600dpi x 1bit
Print Writing
Sharp Advanced Printing Language:
600 x 600dpi x 1bit
PCL:
600 x 600dpi x 1bit
1,200 x 600dpi x 1bit
PS:
600 x 600dpi x 1bit
1,200 x 600dpi x 1bit
Scanning
Resolution (dpi)
Monochrome
Platen 600 x 600dpi
600 x 400dpi
600 x 300dpi (default)
RSPF 600 x 600dpi
600 x 400dpi (default)
Exposure lamp White LED
Reading gradation 10bit
Output gradation BW: 1bit
Grayscale: 8bit
Full Color: each color RGB 8bit
Type Document table fixed system (Flat bed)
Scanning area 297 x 432mm
Original standard
position
Left rear reference
Detection Yes
Detection size Automatic detection (Detection types can be
changed in the system settings)
Dehumidifying
heater
(Scanner section)
Supplied as a service parts
1
: ‘15/Aug.
1
1

Sharp MX-M266N Specifications

General

Print Speed	26 ppm
Print Resolution	600 x 600 dpi
Copy Speed	26 cpm
Scan Resolution	600 x 600 dpi
Duplex Printing	Yes
Fax Speed	33.6 Kbps
Copy Resolution	600 x 600 dpi
Maximum Paper Size	A3
Network Connectivity	Ethernet
Functions	Print, Copy, Scan
Paper Size	A4, A5, B5
Fax Transmission Speed	3 seconds per page
Operating System Compatibility	Windows, Mac, Linux
Paper Capacity	Standard: 500 sheets x 1 tray + 100-sheet bypass tray; Maximum: 2, 100 sheets
