MX-M316N CONSUMABLE PARTS 3 – 3
C. Asia and Hong Kong
* The other maintenance parts than the above are supplied as service parts.
D. Middle East, Africa, Taiwan, Israel and Philippines, Korea
* The other maintenance parts than the above are supplied as service parts.
3. Developer/Drum life end definition
* When the developer/drum counter reaches the specified count.
* When the developer/drum rpm reaches the specified count.
When either of the above reach the specified count, it is judged as life end.
when correction or warm-up operation is performed as well as output operation, the developer and the drum rotates.
Therefore, the developer/drum consuming level cannot be determined only by the copy/print quantity. When, therefore, the rpm reaches the
specified amount, it is judged as life end.
To check the drum and developer life, use SIM22-13.
No. Item Content Life Model name Remarks
1 Upper heat roller kit Upper heat roller x 1 150K MX-313UH
Fuser gear x 1
Upper heat roller bearing x 2
Upper cleaning pad x 1
Fusing separation pawl (upper) x 4
2 Lower heat roller kit Lower heat roller x 1 300K MX-312LH
Fusing separation pawl (lower) x 1
Fuser bearing (lower) x 2
3 Maintenance kit Drum separation pawl unit x 2 100K MX-312KA
Cleaner blade x 1
MC unit x 1
4 Drum frame unit Drum frame unit x 1 300K MX-312DU * The life of the toner reception seat
attached to the drum frame is 300K, and it
can be used up to 3 times.
(Supplied as a drum frame unit.)
5 Transfer roller unit Transfer roller unit x 1 150K MX-312TX
6 Paper feed roller kit Paper feed roller kit x 1 100K MX-312RT
7 Paper feed roller kit Paper feed roller kit x 1 100K MX-312MR
8 Fusing unit Fusing unit (120V heater lamp) x 1 150K MX-312FU1
9 Fusing unit Fusing unit (200V heater lamp) x 1 150K MX-312FU
10 Toner filter unit Toner filter unit x 1 100K MX-312TF
11 Staple cartridge Staple cartridge x 3 5000 staples x 3 MX-SCX1
No. Item Content Life Model name Remarks
1 Upper heat roller kit Upper heat roller x 1 150K MX-313UH
Fuser gear x 1
Upper heat roller bearing x 2
Upper cleaning pad x 1
Fusing separation pawl (upper) x 4
2 Lower heat roller kit Lower heat roller x 1 300K MX-312LH
Fusing separation pawl (lower) x 1
Fuser bearing (lower) x 2
3 Maintenance kit Drum separation pawl unit x 2 100K MX-312KA
Cleaner blade x 1
MC unit x 1
4 Drum frame unit Drum frame unit x 1 300K MX-312DU * The life of the toner reception seat
attached to the drum frame is 300K, and it
can be used up to 3 times.
(Supplied as a drum frame unit.)
5 Transfer roller unit Transfer roller unit x 1 150K MX-312TX
6 Paper feed roller kit Paper feed roller kit x 1 100K MX-312RT
7 Paper feed roller kit Paper feed roller kit x 1 100K MX-312MR
8 Fusing unit Fusing unit (120V heater lamp) x 1 150K MX-312FU1
9 Fusing unit Fusing unit (200V heater lamp) x 1 150K MX-312FU
10 Toner filter unit Toner filter unit x 1 100K MX-312TF
11 Staple cartridge Staple cartridge x 3 5000 staples x 3 MX-SCX1
Developer/drum counter
Number of rotations
(Rotations)
Developer/drum 100K 550K
