Sharp MX-M266N - Page 126

MX-M316N SIMULATION 6 – 47
46-4
Purpose
Adjustment (Color scanner mode)
Function (Purpose)
Used to adjust the density in the image
send mode.
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
* When the key is pressed, the setting value of each
item can be changed with 1up (1down) collectively.
3) Press [OK] key. (The set value is saved.)
When the adjustment value is increased, the image density is
increased, and vice versa.
46-5
Purpose
Adjustment (Monochrome scanner mode)
Function (Purpose)
Used to adjust the density in the image
send mode.
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
* When the key is pressed, the setting value of each
item can be changed with 1up (1down) collectively.
3) Press [OK] key. (The set value is saved.)
When the adjustment value is increased, the image density is
increased, and vice versa.
46-8
Purpose
Adjustment (Color scanner mode)
Function (Purpose)
Used to adjust the image send mode color
balance RGB.
Section
Operation/Procedure
1) Select an adjustment target with [R] [G] [B] keys on the touch
panel.
2) Select an adjustment target item with scroll key on the touch
panel.
3) Enter the set value with 10-key.
4) Press [OK] key. (The set value is saved.)
The color balance can be adjusted separately for the low density
area and the high density area.
When the adjustment value is increased, the image density of the
target color is increased, and vice versa.
46-9
Purpose
Adjustment (RSPF mode)
Function (Purpose)
Used to adjust the scan image density.
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
* When the key is pressed, the setting value of each
item can be changed with 1up (1down) collectively.
3) Press [OK] key. (The set value is saved.)
This adjustment result affects the image send mode, the copy
mode, and the fax mode.
When the adjustment value is increased, the image density is
increased, and vice versa.
Mode Item/Display Content
Setting
range
Default
value
LOW A AUTO Auto 1 - 99 50
B TEXT Text 1 - 99 50
C TEXT/PRINTED
Text/Printed Photo 1 - 99 50
D TEXT/PHOTO Text/Photograph 1 - 99 50
E PRINTED PHOTO Printed Photo 1 - 99 50
F PHOTOGRAPH Photograph 1 - 99 50
G MAP Map 1 - 99 50
HIGH A AUTO Auto 1 - 99 50
B TEXT Text 1 - 99 50
C TEXT/PRINTED
Text/Printed Photo 1 - 99 50
D TEXT/PHOTO Text/Photograph 1 - 99 50
E PRINTED PHOTO Printed Photo 1 - 99 50
F PHOTOGRAPH Photograph 1 - 99 50
G MAP Map 1 - 99 50
Mode Item/Display Content
Setting
range
Default
value
LOW A AUTO TEXT Auto/Text 1 - 99 50
B TEXT Text 1 - 99 50
C TEXT/PRINTED
Text/Printed Photo 1 - 99 50
D TEXT/PHOTO Text/Photograph 1 - 99 50
E PRINTED PHOTO Printed Photo 1 - 99 50
F PHOTOGRAPH Photograph 1 - 99 50
G MAP Map 1 - 99 50
HIGH A AUTO TEXT Auto/Text 1 - 99 50
B TEXT Text 1 - 99 50
C TEXT/PRINTED
Text/Printed Photo 1 - 99 50
D TEXT/PHOTO Text/Photograph 1 - 99 50
E PRINTED PHOTO Printed Photo 1 - 99 50
F PHOTOGRAPH Photograph 1 - 99 50
G MAP Map 1 - 99 50
Item/Display Content
Default
value
A LOW DENSITY POINT Low density correction amount 50
B HIGH DENSITY POINT High density correction amount 50
Item/Display Content
Setting
range
Default
value
A COPY : LOW RSPF copy mode exposure
adjustment (Low density side)
1 - 99
40
B SCAN : LOW RSPF scanner mode exposure
adjustment (Low density side)
1 - 99
40
C FAX : LOW RSPF FAX mode exposure
adjustment (Low density side)
1 - 99
40
D COPY : HIGH RSPF copy mode exposure
adjustment (High density side)
1 - 99
50
E SCAN : HIGH RSPF scanner mode exposure
adjustment (Low density side)
1 - 99
50
F FAX : HIGH RSPF FAX mode exposure
adjustment (high density)
1 - 99
50
