MX-M316N SIMULATION 6 – 61
51
51-1
Purpose
Adjustment
Function (Purpose)
Adjust the ON/OFF timing of the transfer
current.
Section
Operation/Procedure
1) Select an adjustment target item with scroll key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key. (The set value is saved.)
When the adjustment value is decreased, the transfer ON/OFF
timing for the paper is advanced. When the adjustment value
is increased, the timing is delayed. When the adjustment value
is changed by 1, the timing is changed by about 2ms. The set-
ting range is -98 - +98ms.
51-2
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the contact pressure (deflec-
tion amount) on paper by the main unit and
the RSPF registration roller. (This adjust-
ment is performed when there is a consid-
erable variation in the print image position
on the paper or when paper jams frequently
occur.)
Section
Operation/Procedure
1) (When RSPF model)
Select a target adjustment mode with [SIDE1] or [SIDE2] or
[ENGINE] keys.
2) Select a target item to be adjusted with scroll keys.
3) Enter the set value with 10-key.
4) Press [OK] key. (The set value is saved.)
Item Display Content
Default
value
ATC ON
TIMING
Transfer current ON timing setting 50
B TC OFF
TIMING
Transfer current OFF timing
setting
50
Mode Display/Item Content
Setting
range
Default
value
SIDE1 A NORMAL_PLAIN_HIGH RSPF front surface document deflection amount adjustment value
(Normal/Plain paper/HIGH)
- 1 - 99 50
B NORMAL_PLAIN_LOW RSPF front surface document deflection amount adjustment value
(Normal/Plain paper/LOW)
- 1 - 99 50
C NORMAL_THIN_HIGH RSPF front surface document deflection amount adjustment value
(Normal/Thin paper/HIGH)
- 1 - 99 50
D NORMAL_THIN_LOW RSPF front surface document deflection amount adjustment value
(Normal/Thin paper/LOW)
- 1 - 99 50
E RANDOM_PLAIN_HIGH RSPF front surface document deflection amount adjustment value
(Random/Plain paper/HIGH)
- 1 - 99 50
F RANDOM_PLAIN_LOW RSPF front surface document deflection amount adjustment value
(Random/Plain paper/LOW)
- 1 - 99 50
G RANDOM_THIN_HIGH RSPF front surface document deflection amount adjustment value
(Random/Thin paper/HIGH)
- 1 - 99 50
H RANDOM_THIN_LOW RSPF front surface document deflection amount adjustment value
(Random/Thin paper/LOW)
- 1 - 99 50
SIDE2 A NORMAL_PLAIN_HIGH_1 RSPF back surface document deflection amount adjustment value 1
(Normal/Plain paper/HIGH)
- 1 - 99 50
B NORMAL_PLAIN_LOW_1 RSPF back surface document deflection amount adjustment value 1
(Normal/Plain paper/LOW)
- 1 - 99 50
ENGINE A TRAY1(S) Main unit cassette 1 (Upper stage)/deflection adjustment value
(Plain paper/Small size)
LT size (216mm)
or less
1 - 99 25
B TRAY1(L) Main unit cassette 1 (Upper stage)/deflection adjustment value
(Plain paper/Large size)
LT size (216mm)
or above
1 - 99 25
C TRAY2(S) Main unit cassette 2 (Lower stage)/deflection adjustment value
(Plain paper/Small size)
LT size (216mm)
or less
1 - 99 50
D TRAY2(L) Main unit cassette 2 (Lower stage)/deflection adjustment value
(Plain paper/Large size)
LT size (216mm)
or above
1 - 99 50
E MANUAL PLAIN PAPER (S) Manual feed tray/deflection adjustment value (Plain paper/Small size) LT size (216mm)
or less
1 - 99
50
1
: ‘15/Aug.
1
