MX-M316N TROUBLESHOOTING 7 – 3
O: Operation enabled ✕ : Operation disabled
1: The operation is enabled in a line other than the trouble line.
3: When detected during other than a job, the operation is enabled with a tray other than the trouble tray.
4: When detected during other than a job, the operation is enabled in a section other than the trouble paper exit section. * However, it is
valid only when the escape tray setting has been made.
9: When detected during other than a job, the operation is enabled in the black and white mode.
*10: Since communication is enabled, reception can be transferred.
*11: The trouble display is "Display to a 2-line message." (Example: Ready to copy. F2 trouble)
15: FAST notification function (When in U2-22, trouble notification cannot be made. If there is no abnormality in the FAX software or the
FAST data in U2-23, trouble notification can be made.)
Engine trouble 2 * PCU troubles
(motor, fusing, etc.)
PCU F2(40,64,
70,74)
H2(00,01)
H3(00,01)
H4(00,01)
H5(01)
L4(01,11,32,
34,35,40,
44,70)
L8(01,02)
U2 (90, 91)
✕ ✕✕✕✕✕
*10
✕✕
Paper feed tray 1
trouble
* Paper feed tray 1
breakdown
F3 (12) 3
OOO
3 3
*10
O
3
Paper feed tray 2
trouble
* Paper feed tray 2
breakdown
F3 (22) 3
OOO
3 3
*10
O
3
Paper feed tray 3
trouble
* Paper feed tray 3
breakdown
F3 (32, 42) 3
OOO
3 3
*10
O
3
Staple trouble * Staple breakdown F1 (10) 4 4 4 4 4 4
*10
4 4
Finisher trouble * After-process
breakdown
F1 (00, 03,
15, 19, 20,
29, 37)
4 4 4 4 4 4
*10
4 4
Other troubles * Other troubles EE (EL, EU)
O OOOOOOO
Process control
trouble
* Process control
breakdown (PCU
detection)
F2 (39, 58) O
*11
OOOOOOO
Operation disable
trouble
* Connection trouble
(Model data
discrepancy) (SCU
detection)
SCU A0 (22) ✕ ✕✕✕✕✕✕✕
SCU CPT ASIC
trouble
* SCU CPT ASIC
error
UC (02) 9 9 9 9
OO
9
O
SCU ASIC trouble
(SCU detection)
* SCU ASIC error
(SCU detection)
UC (20) ✕ ✕✕✕
OO
✕
O
Scanner trouble 1 * SCU EEPROM
error
U2 (80, 81) ✕ ✕✕✕
OO
✕
O
Scanner trouble 2 * Scanner section
breakdown (mirror
motor, lens, copy
lamp)
L1 (00)
L3 (00)
✕ ✕✕✕
OO
✕
O
CCD trouble * CCD breakdown
(shading, etc.)
E7 (10, 11,
14)
✕ ✕✕✕
OO
✕
O
Trouble content
Judg-
ment
block
Trouble
code
(26cpm/
31cpm/
35cpm)
machine)
Operatable mode
Copy scan
(including
interrup-
tion)
Scan
(Push)
Scan
(Pull)
Scan-
To
HDD
Print
List
print
FAX
Send
FAX
print
