Grease map（Fusing section）
Exit Paper
feed
section
Transport rollers ✕ ○○○○○○○○○○○
Gears ✕ ✕✕✕✕✕✕✕✕✕✕✕
Discharge brush ✕ ✕✕✕✕✕✕✕✕✕✕✕
Transport paper guides ○ ○○○○○○○○○○○
Sensors ✕ ✕✕✕✕✕✕✕✕✕✕✕
Paper feed
section/
Transport
section
(RSPF)
Paper feed roller ○ ○○○○○○○○○○○Replacement reference:
Replace according to the SPF
paper feed counter value.
SPF section roller:
100K or 1 year of use
When replacing the paper feed
roller, apply grease to the paper
feed shaft.
(UKOG-0013QSZZ)
Pickup roller ○ ○○○○○○○○○○○
Separation roller ○ ○○○○○○○○○○○
Torque limiter ✕ ✕✕✕✕✕✕✕✕✕✕✕Replacement reference:
Replace according to the SPF
paper feed counter value.
SPF section torque limiter:
400K or 2 years of use
Discharge brush ✕ ✕✕✕✕✕✕✕✕✕✕✕
Transport rollers ○ ○○○○○○○○○○○
Sensors ✕ ✕✕✕✕✕✕✕✕✕✕✕
Scanning plate ○ ○○○○○○○○○○○
Gears ✕ ✕✕✕✕✕✕✕✕✕✕✕
Belts ✕ ✕✕✕✕✕✕✕✕✕✕✕
OC mat ○ ○○○○○○○○○○○
When
calling
100
k
150
k
200
k
300
k
400
k
450
k
500
k
600
k
700
k
750
k
800
k
Remark
conntact point of plates.
conntact point of plates.
Grease
UKOG-0235FCZZ
Grease
UKOG-0235FCZZ
Grease
UKOG-0235FCZZ
Grease
UKOG-0255FCZZ
Grease
UKOG-0235FCZZ
