MX-M316N SIMULATION 6 – 13
8
8-1
Purpose
Operation test/check/adjustment
Function (Purpose)
Used to check and adjust the operations of
the developing voltage in each print mode
and the control circuit.
Section
Process (Developing)
Operation/Procedure
1) Select a mode with [TS_OFF] and [TS_ON] keys on the touch
panel.
2) Select a target item to be adjusted with scroll keys.
3) Enter the setting value with 10-key. (The value specified on the
label of the high voltage PWB must be entered.)
* When the key is pressed, the setting value of each
item can be changed with 1up (1down) collectively.
4) Press [EXECUTE] key.
The set value is saved and the voltage entered with step 3) is
output for 30 sec.
When [EXECUTE] key is pressed, the output is terminated.
8-2
Purpose
Operation test/check/adjustment
Function (Purpose)
Used to check and adjust the operation of
the main charger grid voltage in each
printer mode and the control circuit.
Section
Process (Charging)
Operation/Procedure
1) Select a mode with [TS_OFF] and [TS_ON] keys on the touch
panel.
2) Select a target item to be adjusted with scroll keys.
3) Enter the adjustment value with 10-key. (The value specified
on the label of the high voltage PWB must be entered.)
* When the key is pressed, the setting value of each
item can be changed with 1up (1down) collectively.
4) Press [EXECUTE] key.
The set value is saved and the voltage entered with step 3) is
output for 30 sec.
When [EXECUTE] key is pressed, the output is terminated.
Item/Display (Mode) Content
Adjust
ment
range
Default value
26
cpm
31
cpm
35
cpm
TS_
OFF
ACOPY
DVB
Developing
bias set value
in a copy job
(Toner save
mode OFF)
0 - 650
400 400 430
B PRINTER
FAX DVB
Developing
bias set value
in a PRINT/
FAX job (Toner
save mode
OFF)
0 - 650
400 400 430
TS_
ON
ACOPY
DVB
Developing
bias set value
in a copy job
(Toner save
mode ON)
0 - 650
320 320 320
B PRINTER
DVB
Developing
bias set value
in a print job
(Toner save
mode ON)
0 - 650
250 250 250
Item/Display (Mode) Content
Adjust
ment
range
Default value
26
cpm
31
cpm
35
cpm
TS_
OFF
A COPY GB Charging/grid
bias set value
in a copy job
(Toner save
mode OFF)
0 - 750
575 575 605
B PRINTER
FAX GB
Charging/grid
bias set value
in a PRINT/
FAX job (Toner
save mode
OFF)
0 - 750
575 575 605
TS_
ON
A COPY GB Charging/grid
bias set value
in a copy job
(Toner save
mode ON)
0 - 750
495 495 495
B PRINTER
GB
Charging/grid
bias set value
in a print job
(Toner save
mode ON)
0 - 750
495 425 425
