Shimadzu GC-2014 Series User Manual

Chapter 3 Gas-Flow Controller
GC-2014 Service Manual
65
1PC, RESISTANCE TUBE, HYDROGEN, GC-8A
27 201-47435
4PC, RUBBER PLUG, PORT, SILICON
28 221-09864-18
2PC, PIPE, MF-MM17, 2 × 180
29 221-41408-94
1PC, PIPE, PG-MF-MF ASSY
32 221-19503-08
2PC, RESISTANCE TUBE, AIR, GC-8AF
33 221-41410-91
2PC, PIPE, M5-MF ASSY
34 221-41527-92
1PC, PIPE, PG-MF-MF-MMASS
36 221-70720-02
1PC, FPD, RESISTANCE TUBE
37 201-48557-25
2PC, PIPE, MN2W-MM2W
38 072-83071-08
1PC, MARK BAND H
39 072-83071-01
1PC, MARK BAND A
3.1.2.3 FPD
Reference No.
221-70049-93 11 221-18150-91
FLOW CONTROLLER, 2PC, N BELLOW VALVE, 2K
H2-AIR, FPD
16 670-18558-11
2PC, PRESSURE GAUGE, 200 KPA
17 018-21330
TAPE, STICKER, 0.1 × 13 × 5
20 221-42080-92
1PC, BRANCHED PIPE, AIR, FPD, V2
22 221-70483-91
1PC, SOLENOID VALVE ASSY
24 035-60395-43
2PC, GASKET
25 221-31745
2PC, HOUSING
26 221-19502-08

Shimadzu GC-2014 Series Specifications

General

Type	Gas Chromatograph
Detector Options	FID, TCD, ECD, FPD, FTD
Display	LCD
Injection Ports	Up to 3
Column Options	Capillary, Packed
Data System	GCsolution software
Weight	Approx. 45 kg
Number of Detectors	Up to 4 detectors
Injection Port	Split/Splitless
Power Requirements	100-240V AC, 50/60Hz
