Chapter 2 Configuration of GC-2014
GC-2014 Service Manual
13
2.1.6 GC-2014ATF
221-70026-91 221-70051-91
GC-2014ATF,100V GC-2014ASSY,100V
115V:221-70026-92 115V:221-70051-92
230V:221-70026-34 230V:221-70051-34
221-70080-91
PACKEDDUAL
INJ,100V
115V:221-70080-92
230V:221-70080-34
221-70075-91
DULA
AFC ASSY
221-70090-91
FID-2014 CELL ASSY,P
221-70040-91
FID-2014 CONTROLLER,DUAL
221-70086-91
DET HEATER ASSY,FT,100V
115V:221-70086-92
230V:221-70086-34
221-70049-91
FLOWCONTROLLER
,H2-AIR,FID
221-70063-91
ACCESSORY
,GC-2014
221-70098-91
TCD-2014 CELL ASSY,100V
115V:221-70098-92
230V:221-70098-34
221-70041-91
TCD-2014 CONTROLLER
221-70043-91
TCD POWER SUPPLY ASSY
221-11386-91
TCD ACCESSORY SET
⑲①
②
③
⑤
⑥
⑭
⑧
⑱
④
⑮
⑯
⑰
