Chapter 2 Configuration of GC-2014
GC-2014 Service Manual
12
2.1.5 GC-2014AT
221-70027-91 221-70051-91
GC-2014,AT100V GC-2014ASSY,100V
115V:221-70027-92 115V:221-70051-92
230V:221-70027-34 230V:221-70051-34
221-70080-91
PACKED DUAL INJ,100V
115V:221-70080-92
230V:221-70080-34
221-70075-91
DUAL AFC ASSY
221-70086-91
DET HEATER ASSY,FT,100V
115V:221-70086-92
230V:221-70086-34
221-70063-91
ACCESSORY,GC-2014
115V:221-70063-91
230V:221-70063-96
221-70098-91
TCD-2014 CELL ASSY,100V
115V:221-70098-91
230V:221-70098-34
221-70041-91
TCD-2014 CONTROLLER
221-70043-91
TCD POWER SUPPLY ASSY
221-11386-91
TCD ACCESSORY SET
⑱
④
⑮
⑯
⑰
①
②
③
⑭
