Shimadzu GC-2014 Series - Ftd-2014, Capillary; Ftd-2014, Packed; Ecd-2014

Chapter 6 Maintenance Parts Lists
GC-2014 Service Manual
97
< FTD-2014, CAPILLARY >
P/N Part name Remarks
201-48386 3-WAY SPLIT TUBING, M-TYPE
221-18713-95 RESISTANCE TUBE ASSY, H2 For FTD
221-18713-96 RESISTANCE TUBE ASSY, AIR FTD-9 For FTD
221-21910 INSULATOR, CERAMIC
221-19502-08 RESISTANCE TUBE, H2 Resistance tube only (for make-up gas)
221-31745 HOUSING, RESISTANCE TUBE
221-34121-94 MS FILTER Aged
221-48258-91 NOZZLE ASSY, FID
221-41532-92 GRAPHITE POSITIONING JIG, FID
221-45586-91 FTD COLLECTOR (GC-2010)
221-46520-92 FTD-2014 CONTROLLER
221-48457-92 FTD-2010 POWER CONTROLLER
221-47658-91 MAIN PART, BASE ASSY, FTD
221-70049-92 FLOW CONTROLLER, H2-AIR-FTD
221-47660-91 HEATER, PT, ASSY, 120V, DET FID, 100V
221-47660-98 HEATER, PT, ASSY, 240V, DET FID, 200 V
< FTD-2014, PACKED >
P/N Part name Remarks
201-48386 3-WAY SPLIT TUBING, M-TYPE
221-18713-95 RESISTANCE TUBE ASSY, H2 For FTD
221-18713-96 RESISTANCE TUBE ASSY, AIR FTD-9
221-34121-94 MS FILTER Conditioned
221-70162-92 NOZZLE ASSY, PACKED
221-18704-91 FTD COLLECTOR (STANDARD) For general use
221-42512-91 FTD COLLECTOR (SPECIAL) For pesticide analysis
221-46520-92 FID-2014 CONTROLLER
221-48457-92 CONTROLLER, FTD-2014
221-70298-91 MAIN PART, BASE ASSY, FID
221-70049-92 FLOW CONTROLLER, H2-AIR-FTD
221-70610-91 FID-2014 HEATER ASSY, 100
221-70610-34 FID-2014 HEATER ASSY, 230
221-70662 FTD CABLE, PTFE PACKING Collector-cover packing
< ECD-2014 >
P/N Part name Remarks
221-70049-94 FLOW CONTROLLER, AUX
221-70623-91 ECD-2014, HEATER ASSY, 100 FID, 100 V
221-70623-34 ECD-2014, HEATER ASSY, 230 FID, 230 V
221-48455-92 ECD-2014 CONTROLLER
221-33193-91 CAPILLARY ADAPTER, DET SIDE
221-34121-94 MS FILTER Aged
221-19502-08 RESISTANCE TUBE ASSY, H2 Resistance tube only (for make-up gas)
221-31745 HOUSING, RESISTANCE TUBE
