Shimadzu GC-2014 Series User Manual

Chapter 6 Maintenance Parts Lists
GC-2014 Service Manual
95
Chapter 6 Maintenance Parts Lists
<GC-2014 MAIN UNIT>
P/N Part name Remarks
072-01665-36 FUSE, 15A 100 V
072-02004-23 FUSE, 218, 15A 100 V
072-01665-34 FUSE, 10A 200 V
072-02004-21 FUSE, 218, 3.15A 200 V
074-73307-01 LITHIUM BATTERY CR2032
074-80427-61 POWER SUPPLY, LEA100F-24 200 V
074-80654-77 POWER SUPPLY, VS100B-24 100 V
221-48721-91 LCD ASSY, GC-2010 Equipped with gasket
201-35584 RUBBER SEPTUM, INJ. PORT 20 per set
221-12949 FAN 100 V, 200 V
221-32126-05 GRAPHITE FERRULE, G-0.5 10 per set
221-32126-08 GRAPHITE FERRULE, G-0.8 10 per set
036-11203-84 O-RING, 4D, P5 For INJ (5 per set)
221-32705 CAP NUT, M5×0.5, SLOTTED
221-16325 NUT, NOT SLOTTED
221-34121-94 BUFFER TUBE ASSY Aged
221-41286 SEPTUM NUT
221-41444 GLASS INSERT, SPL17
221-43597 COVER, RADIATING FIN
221-49613-91 HEATER ASSY, COLUMN OVEN, 100 V
221-49613-92 HEATER ASSY, COLUMN OVEN, 115 V
221-49613-34 HEATER ASSY, COLUMN OVEN, 230 V
221-43695-91 PT SENSER ASSY, COLUMN OVEN
221-43696-91 THERMOCOUPLE ASSY, COLUMN OVEN
221-43710 HOLDER, PT SENSOR
221-44584 NEEDLE GUIDE, AOC
221-70254-91 PCB DET I/F, GC2014
221-45745-91 PCB FLOW I/F, GC-2010
221-70250-91 PCB KEY ASSY, GC-2014
221-46470-01 KEY RUBBER 1, KEY PANEL
221-46471-01 KEY RUBBER 2, KEY PANEL
221-70602-91 HEATER, PT ASSY, SPL100
221-70602-34 HEATER, PT ASSY, SPL230
221-47632-92 CPU UNIT, GC-2014
221-70072-91 FAN MOTOR ASSY, 100 V
221-70072-92 FAN MOTOR ASSY, 120 V
221-70072-34 FAN MOTOR ASSY, 230 V
221-47652 FLAP MOTOR
221-47653-91 POWER SWITCH ASSY
221-70082-81 SPL-2014 STOCKED,100-120
●
SPL, 100 V (tested for gas leaks and aged)
221-70082-38 SPL-2014 STOCKED,220-240
●
SPL, 200 V (tested for gas leaks and aged)
221-47735-93 AFC-2014 ASSY
●
For SPL
221-48335-01 GLASS INSERT, SPLITLESS/WBI
221-48398-91 HIGH-TEMPERATURE SEPTUM 20 per set
221-48460-92 POWER UNIT 100 V
221-48460-39 POWER UNIT, CE 200 V
221-48600 SILICA WOOL, 2 G Deactivated
221-47251-91(-31)
CHROMATOPAC SIGNAL CABLE, WIDE (CE)
For wide-range output ("-31" model is CE compatible.)
221-47251-92(-32)
CHROMATOPAC SIGNAL CABLE, LINEAR (CE)
For linear output ("-32" model is CE compatible.)

Shimadzu GC-2014 Series Specifications

General

Type	Gas Chromatograph
Detector Options	FID, TCD, ECD, FPD, FTD
Display	LCD
Injection Ports	Up to 3
Column Options	Capillary, Packed
Data System	GCsolution software
Weight	Approx. 45 kg
Number of Detectors	Up to 4 detectors
Injection Port	Split/Splitless
Power Requirements	100-240V AC, 50/60Hz
