Shimadzu GC-2014 Series User Manual

Chapter 6 Maintenance Parts Lists
GC-2014 Service Manual
96
< FID-2014, SINGLE >
P/N Part name Remarks
221-70610-91 FID-2014 HEATER ASSY, 100 FID, 100 V
221-70610-34 FID-2014 HEATER ASSY, 230 FID, 200 V
221-70630-91 FID-2014 CELL BASE ASSY
221-47659-91 COLLECTOR ASSY, FID
221-46520-92 FID-2014 CONTROLLER
221-21910 INSULATOR, CERAMIC For FID collector
221-19503-08 RESISTANCE TUBE, AIR Resistance tube only (for air)
221-19502-08 RESISTANCE TUBE, H2 Resistance tube only (for make-up gas)
221-31745 HOUSING, RESISTANCE TUBE
221-70091-91 FID-2014 ASSY, 100-120 V FID, 100 V
221-70091-98 FID-2014 ASSY, 220-240 V FID, 200 V
201-48386 3-WAY SPLIT TUBING, M-TYPE
221-70162-92 NOZZLE ASSY, PACKED
221-41532-98 GRAPHITE POSITIONING JIG, FID-2014
221-41847-93 FILAMENT ASSY, FID
221-70049-91 FLOW CONTROLLER, H2-AIR, FID
221-70298-91 BASE, MAIN ASSY, FID
221-47146-92 HIGH VOLTAGE ELECTRODE, FID2014
< FPD-2014 >
P/N Part name Remarks
221-70562 FPD PACKING
036-11022 O-RING, 4C, P22
201-48386 3-WAY SPLIT TUBING, M-TYPE
221-19502-08 RESISTANCE TUBE, H2 Resistance tube only (for H
2
)
221-31745 HOUSING, RESISTANCE TUBE
221-33193-91 CAPILLARY ADAPTER, DET SIDE
221-46552 SILICA TUBE, LARGE
221-46310-01 S FILTER, FPD (GC-2010)
221-46310-02 G FILTER, FPD (GC-2010)
221-46310-03 Sn FILTER, FPD (GC-2010)
221-48456-92 FPD-2010 CONTROLLER
221-45647-92 IGNITER ASSY, FPD
221-70617-91 FPD-2014, HEATER UNIT, 100 FPD, 100 V
221-70617-34 FPD-2014, HEATER UNIT, 230 FPD, 200 V
221-70778-91 FAN ASSY, FPD For filter cooling
221-70049-93 FLOW CONTROLLER, H2-AIR, FPD
221-48578 PHOTOMULTIPLIER, R5983

Shimadzu GC-2014 Series Specifications

General

Type	Gas Chromatograph
Detector Options	FID, TCD, ECD, FPD, FTD
Display	LCD
Injection Ports	Up to 3
Column Options	Capillary, Packed
Data System	GCsolution software
Weight	Approx. 45 kg
Number of Detectors	Up to 4 detectors
Injection Port	Split/Splitless
Power Requirements	100-240V AC, 50/60Hz
