Chapter 5 Detector Unit

GC-2014 Service Manual

Configuration Diagram for FTD-2014

11 221-70458-91(-34)

1PC HEATER, PT ASSY, 100V (230V) DET

12 221-70121

1PC DET, SINGLE, UPPER COVER

13 221-70129

1PC RETAINER PLATE, DET, SINGLE

14 221-70138

1PC LOCK RING, DET, SINGLE

16 221-70134

1PC DET, SINGLE, BLOCK, UPPER

17 221-70135

1PC DET, SINGLE, BLOCK, LOWER

31 020-46534

4PC SCREW, SUS, SEMS, P3, M3×6

34 020-46640

2PC SCREW, SUS, SEMS, P4, M3×25

35 020-46542

2PC SCREW, SUS, SEMS, P3, M3×30
