OUT1 (Control output 1)
Relay contact : 1a1b
Control capacity,
3A 250V AC (resistive load)
1A 250V AC (inductive load cos
=0.4)
Electrical life: 100,000 cycles
Non-contact voltage : For SSR drive
12
+2
,
0
V DC maximum 40mA DC (short circuit protected)
DC current : 4 to 20mA DC (Isolated type)
Load resistance, maximum 550
Alarm 1 output
The alarm action point is set by the
deviation from the SV (except Process alarm).
[When the alarm action is set as Energized]
When the input goes outside the range, the output turns ON or OFF (in the case
of High/Low limit range alarm).
[When the alarm action is set as De-energized]
The output acts conversely.
One alarm can be selected by Rotary switch and DIP switch from 13 types of alarm,
plus Pattern end output: High limit alarm, Low limit alarm, High/Low limits alarm,
High/Low limit range alarm, Process high alarm and Process low alarm, the standby
function which is applied to them respectively, as well as No alarm and Pattern end
output.
Setting accuracy : The same as Indication accuracy
Action : ON/OFF action
Hysteresis : Thermocouple, RTD input: 0.1 to 100.0
( )
DC input: 1 to 1000 (The placement of the decimal point follows
the selection.)
Output : Relay contact 1a
Control capacity, 3A 250V AC (resistive load)
1A 250V AC (inductive load cos
=0.4)
Electrical life: 100,000 cycles
Controlling action
The fuzzy self-tuning PID, PID, PD or ON/OFF control is selectable by DIP switch.
Fuzzy self-tuning PID control
Proportional band (P) : Automatic
Integral time (I) : Automatic
Derivative time (D) : Automatic
Anti-reset windup (ARW) : Automatic
Proportional cycle : 1 to 120 sec
Output high/low limit : 0 to 100% (DC current output: –5 to 105%)
PID control (with AT function)
Proportional band (P) : 0.1 to 999.9%
Integral time (I) : 0 to 3600 sec (off when set to 0)
Derivative time (D) : 0 to 3600 sec (off when set to 0)
Anti-reset windup (ARW) : Automatic
Proportional cycle : 1 to 120 sec
Output high/low limit : 0 to 100% (DC current output, –5 to 105%)
