55
Insulation resistance
10M
or more, at 500V DC
An insulation test must not be carried out between A-B in the case of (*1) above, and
between A-F, B-F, A-G, B-G, C-D-E and F-G in the case of (*2) above because they are
not electrically insulated from each other.
Dielectric strength
Between input terminal and ground terminal, 1.5kV AC for 1 minute
Between input terminal and power terminal, 1.5kV AC for 1 minute
Between output terminal and ground terminal, 1.5kV AC for 1 minute
Between output terminal and power terminal, 1.5kV AC for 1 minute
Between power terminal and ground terminal, 1.5kV AC for 1 minute
Weight : Approx. 500g
External dimensions: 96 x 96 x 100mm (W x H x D)
Material : Case: Flame-resistant resin
Color : Case: Light gray
Attached functions : Control output OFF function
Set value lock
SV high/low limit
Sensor correction
Multi-range
Multi-function
Simplified programmable controller
Power failure countermeasure
Self-diagnosis
Automatic cold junction temperature compensation
Sensor burnout (Overscale, Underscale)
Warm-up display
SV ramp
Accessories : Mounting brackets 1 set
Instruction manual 1 copy
Unit label 1 label
Current transformer 1 piece each
(CTL-6S) (When W (20A) option is added.)
(CTL-12-S36-10L1U) (When W (50A) option is added.)
Current transformer 2 pieces each
(CTL-6S) (When W3 (20A) option is added.)
(CTL-12-S36-10L1U) (When W3 (50A) option is added.)
Terminal cover 2 pieces (When TC option is added.)
Gasket 1 piece (When IP option is added)
Auxiliary frame 1 piece (When IP option is added)
