Hooking Up Your PRSalpha
Powering the PRSalpha Control Box
The power to the PRSalpha Control Box should be wired into a fused disconnect by a
licensed electrician familiar with industrial equipment.
The Power Requirements for the PRSalpha Control Box and Router/Spindle vary according to
your configuration. The table below outlines some of the power requirements for different
configurations. A schematic for the power requirements for your specific configuration can
be found in the door of the PRSalpha Control Box
Since the power requirements for a Porter Cable router and for a Spindle are different, we
install different components in the PRSalpha Control Box depending on which you will be
using. This is not user configurable. You specified which you would be using at the time you
placed the order.
ShopBot Configuration PRSalpha: US Standard, 60Hz
PRSalpha Control Box and Porter Cable Router
220V single phase, 25A circuit. The 2 legs will be split into two 110 circuits inside the
PRSalpha Control Box: one for the PRSalpha Control Box, and one for the router.
PRSalpha Control Box and Spindle (3 phase)
110V 25A circuit for the PRSalpha Control Box plus 230V 3-phase circuit for the spindle.
Specifications for full-load current of the different models of spindle are provided with the
spindle.
PRSalpha Control Box and Spindle (single phase)
110V 25A circuit for the PRSalpha Control Box plus 220V single phase circuit for the spindle.
Specifications for full-load current of the different models of spindle are provided with the
spindle.
PRSalpha Control Box and two Porter Cable routers
220V single phase, 30A circuit. The 2 legs will be split into two 110 circuits inside the
PRSalpha Control Box: one for the PRSalpha Control Box, and one for the two routers.
PRSalpha Control Box and two Spindles
110V 25A circuit for the PRSalpha Control Box plus the appropriate 220V or 230V circuit for
the spindles.
ShopBot Configuration PRSalpha: European Standard, 50Hz
PRSalpha Control Box and 230V/50Hz Porter Cable Router (single speed)
230V single phase line with 15A circuit for the PRSalpha Control Box plus 15A/230V single
phase line for the Porter Cable Router.
PRSalpha Control Box and Spindle (3-phase)
230 V single phase circuit (15A) for the PRSalpha Control Box plus 380V 3-phase circuit for
the Spindle. Specifications for full-load current of the different models of spindle are
provided with the spindle.
