ShopBot PRS Assembly Manual Page -18
Step 1.4: Slide the Cross Supports into Position
Attach two 5/16” Hardware Assemblies to each end of the Cross Supports. Then slide the T-
nuts into the bottom channels of the Table Sides and slide the Cross Supports into position.
Refer to the Measured Drawing for your table size for proper spacing of the Cross Supports.
Cross Supports in position
