ShopBot PRSalpha - Page 88

.000
36.250
1
2
6
7
.000
3.375
109.625
120.000
.000
76.500
(60.0)
96.0
18.0
42.0
6.75
DECK
ONLY
28.015
53.500 78.042
VIEW A
SEE NOTE 2
4
3
5
Item No. Qty Part Number Description
1 2 000925-01 TABLE SIDE 96E
2 6 000919-01 TABLE LEG 6E
3 6 000770-01 TABLE GUSSET
4 4 001486-01 TABLE SUPPORT UPPER 60E
5 3 001487-01 TABLE SUPPORT LOWER 60E
6 2 001485-01 TABLE SUPPORT CROSS 60E
7 6 000661-01 MACHINE GLIDE
8 6 000160-01 NUT HEX 5/8-11 Z5
10 72 000727-01 NUT T HEAVY DUTY 5/16-18
11 72 000529-01 HCS 5/16-18 X 3/4 Z5
12 72 000848-01 WASHER FLAT 5/16 Z USS
13 40 000589-01 HCS 1/2-13 X 1 1/2 Z5
14 40 000440-01 NUT HEX 1/2-13 Z
15 80 000029-01 WASHER FLAT 1/2 USS Z
16 40 000588-01 WASHER LOCK 1/2 Z
17 48 000953-01
BOLT CARRIAGE 3/8-16 X 1 1/2
18 48 000452-01 NUT HEX 3/8 Z
19 48 000444-01 WASHER FLAT 3/8 USS Z
20 48 000092-01 WASHER LOCK 3/8 Z
21 8 001539-01 TABLE SIDE END CAP
5
4
ECO #198
NONE
REV
DRAWING NUMBER
BY
B
6
REV
5
APVD
C
JLK
C
DGC
5/12/09
10633-00
1
APPROVED
TABLE 96-60-8S
2
THIS DOCUMENT CONTAINS CONFIDENTIAL
INFORMATION OF SHOPBOT TOOLS. IT IS
NOT TO BE REPRODUCED BY ANY MEANS OR USED TO FURNISH INFORMATIONTO OTHERS
WITHOUT THE EXPRESS CONSENT TO THE
OWNER. THE INFORMATION SHALL BE USED BY
RECIPIENTS ONLY AS EXPRESSLY APPROVED
BY OWNER AND THIS DOCUMENT SHALL BE
RETURNED TO OWNER UPON REQUEST.
©2004, SHOPBOT TOOLS, INC.,
ALL RIGHTS RESERVED
ADDED CENTER LEG
REVISION DESCRIPTION
B
A
1
SCALE
10633-01
©2004 , S HOPBOT TOOLS, INC., ALL RIGHTS RESERVED
3
B
4
D
SIZE
D
Durham, North Carolina
2
A
DRAWN CHECKED
TITLE
1
6
06/20/07
DATE
CHG NOTICE
1
PART NUMBER
3
DATE
NOTES:
1. ALL DIMENSIONS ARE IN INCHES.
2. RECOMMENDED SIZE AND ORIENTATION
OF DECK MATERIAL.
