ShopBot PRSalpha - Page 93

.000
36.250
2
6
7
1
.000
24.571
40.073
55.575
77.500
98.580
114.082 129.584 157.625 168.000
.000
76.500
3.375
(144.0)
(60.0)
93.0
93.0
18.0
51.0
51.0
42.0
6.75
DECK
ONLY
VIEW A
SEE NOTE 2
4
3
5
Item No. Qty Part Number Description
1 2 001581-01 TABLE SIDE 144E
2 6 000919-01 TABLE LEG 6E
3 6 000770-01 TABLE GUSSET
4 4 001486-01 TABLE SUPPORT UPPER 60E
5 3 001487-01 TABLE SUPPORT LOWER 60E
6 6 001485-01 TABLE SUPPORT CROSS 60E
7 6 000661-01 MACHINE GLIDE
8 6 000160-01 NUT HEX 5/8-11 Z5
9 6 000845-01 WASHER LOCK 5/8 Z
10 88 000727-01 NUT T HEAVY DUTY 5/16-18
11 88 000529-01 HCS 5/16-18 X 3/4 Z5
12 88 000848-01 WASHER FLAT 5/16 Z USS
13 40 001956-01 HCS 1/2-13 X 1 1/2 Z5
14 40 000440-01 NUT HEX 1/2-13 Z
15 80 000029-01 WASHER FLAT 1/2 USS Z
16 40 000588-01 WASHER LOCK 1/2 Z
17 72 000953-01 BOLT CARRIAGE 3/8-16 X 1 1/2
18 72 000452-01 NUT HEX 3/8 Z
19 72 000444-01 WASHER FLAT 3/8 USS Z
20 72 000092-01 WASHER LOCK 3/8 Z
21 8 001539-01 TABLE SIDE END CAP
SCALE
SIZE REV
B
DRAWING NUMBER
PART NUMBER
REV CHG NOTICE REVISION DESCRIPTION
10638-00
10638-01
0
06/20/07 DGC
BY DATE
INITIAL PRODUCTION RELEASE DGC
06/20/07
0
Durham, North Carolina
TABLE 144-60-8S
DRAWN CHECKED DATE
APPROVED
TITLE
APVD
NONE
21
D
C
B
21
©2004, SHOPBOT TOOLS, INC., ALL RIGHTS RESERVED
3456
3456
AA
D
C
B
THIS DOCUMENT CONTAINS CONFIDENTIAL
INFORMATION OF SHOPBOT TOOLS. IT IS
NOT TO BE REPRODUCED BY ANY MEANS OR USED TO FURNISH INFORMATIONTO OTHERS
WITHOUT THE EXPRESS CONSENT TO THE
OWNER. THE INFORMATION SHALL BE USED BY
RECIPIENTS ONLY AS EXPRESSLY APPROVED
BY OWNER AND THIS DOCUMENT SHALL BE
RETURNED TO OWNER UPON REQUEST.
©2004, SHOPBOT TOOLS, INC.,
ALL RIGHTS RESERVED
NOTES:
1. ALL DIMENSIONS ARE IN INCHES.
2. RECOMMENDED SIZE AND ORIENTATION
OF DECK MATERIAL.
