Appendix
11-2 MORPHEUS MRI
11.1 Technical sheet
INTENDED USE
The MORPHEUS LT/MRI is an anaesthesia unit that can be used on adult,
children and newborn patients.
The MORPHEUS LT/MRI is an anaesthesia machine compatible for Magnetic
Resonance rooms from 1,5 T (15000 G) and from 3 T (30000 G) and
positionable at a min. distance from the magnet corresponding to a field of 20
mT (200 G).
The MORPHEUS LT/MRI is suitable for administration of Oxygen - Air -Nitrous
Oxide - Halothane - Enflurane - Isoflurane - Sevoflurane - Desflurane mixtures.
GENERAL
DESCRIPTION
The MORPHEUS LT/MRI anaesthesia unit is completed with:
• mechanic gas mixing system
• electronic lung ventilator with dual colour display
• valves group: open, semi-closed, closed, heated, with soda lime absorber of
1,5 Kg. capacity
• SIARETEX rapid connection device, Selectatec compatible for 2 vaporizers
• gas supply group
Structure Light aluminium alloy and plastic moulds (a magnetic material)
Wheels Pivoting antistatic wheels, diameter 100 mm (2 with brakes)
Cylinder support No. 2 vertical cylinders supports, on the back side (for cylinders up to 10 litres
capacity) and round rubber pads.
For cylinder aluminium MRI compatible only.
Support for 2 vaporizers On horizontal guide (SIARETEX rapid connection device,
for 2 vaporizers)
Auxiliary power supply
outlets
No. 1 schuko 220 Vac outlet (max. 6 A)
Work shelf lighting 12Vdc by led
Dimensions 71 x 77 x 138 (L x P x H) cm
Weight 72 kg (without accessories)
Environmental conditions
• Temperature from 10 to 40°C
• Relative humidity from 10 to 90% non-condensing
