Description
2-12 MORPHEUS MRI
2.4.2 Connectors for services ( 24 )
MORPHEUS LT/MRI
24.1 EXP FLOW : connectors for flow sensor connection
24.3 PROG : connector for CPU board programming
24.4 PAW OUT : connector for measuring the PAW by external monitor.
WARNING! Risk of equipment failure.
24.1 : white hose connected up, blue hose connected down
WARNING! Risk of equipment failure.
Use and connect devices authorized by Siare, only.
