AD.A module
5-6 MORPHEUS MRI
5.2 Monitoring areas and functional areas
A. Ventilation parameters monitoring
area
B. Controls for preliminary tests on
device
C. User’s controls area and operative
mode selection.
D. Ventilation parameters setting area
E. Selection of default respiratory
parameters (newborn baby, child,
adult)
F. Alarms
Use of encoder knob
• After having selected the parameter
to be modified (D area).
• Turn the encoder clockwise
(counter-clockwise) to increase
(decrease) the parameter value;
press the encoder to confirm the
new set value.
