S5 Description
4-4 MORPHEUS MRI
Low flows oxygen
rotameter
Scale 0.1 - 1 l/min.
Resolution: 0.05 l/min
Accuracy: ± 10% of read value or: ± 1% of end scale whichever is
the worst case.
Low flow nitrous
oxide rotameter
Scale: 0.1 - 1 l/min.
Resolution: 0.05 l/min
Accuracy: ± 10% of read value or: ± 1% of end scale whichever is
the worst case.
Medical gas supply
OXYGEN
• Pressure included between 280 kPa and 600 kPa (2,8 - 6 bar)
• Max. required flow 90 l/min.
NITROUS OXIDE
• Pressure included between 280 kPa and 600 kPa (2,8 - 6 bar)
• Max. required flow 15 l/min.
MEDICAL COMPRESSED AIR
• Pressure included between 280 kPa and 600 kPa (2,8 - 6 bar)
• Max. required flow 90 l/min.
Gauges
No. 3 on front panel (O
2
- N
2
O - AIR ), scale 0 - 6 bar
Alarms
Lack or low oxygen pressure with consequent cut-off of Nitrous
Oxide delivery.
