AD.A module
5-18 MORPHEUS MRI
Ventilation parameters displaying
• Press the key alongside the ventilation parameters monitoring to display in
sequence other available values.
VM (l) Minute volume It indicates the value of minute volume expired
by the patient.
The displayed value is in function of the
parameters: Vt and RATE set.
Vte (ml) Expired Tidal Volume It indicates the value of tidal volume during
the patient expiratory phase.
In case of differences higher than 20% between set volume i(Vt) and
measured value of expired tidal volume (Vte), it is necessary to perform
the flow sensor calibration (see following cfr.).
RATE
(bpm)
Respiratory rate It indicates the real respiratory rate value
