TROUBLESHOOTING 5
8015078/145N/2019-05 -24 | SICK STEGMANN OPERATING INSTRUCTIONS | AFS60/AFM60 PROFINET
61
Subject to change without notice
Subindex .4 – Current warnings
Bit
Designation
Data values
31 … 7
Reserved
–
6
Reserved
–
5
Reserved
–
4
Reserved
–
3
Reserved
–
2
Low power output from the light source for the optical
scanning (LED)
0 = Not active
1 = Active
1
Operating temperature exceeded
0 = Not active
1 = Active
0
Maximum frequency exceeded
0 = Not active
1 = Active
Table 49: Subindex .4 – Current warnings
Subindex .5 – Supported warnings
Bit
Designation
Data values
31 … 7
Reserved
–
6
Reference point
0 = Not supported
5
Battery voltage too low
0 = Not supported
4
Operating time exceeded
0 = Not supported
3
CPU watchdog status
0 = Not supported
2
Low power output from the light source for the optical
scanning (LED)
1 = Supported
1
Operating temperature exceeded
1 = Supported
0
Maximum frequency exceeded
1 = Supported
Table 50: Subindex .5 – Supported warnings
The errors can, once they have been detected by the control system, be reset via bit 15
of the sensor 1 control word (G1_STW). This is only possible if the cause of the error
has been rectified and the status of the encoder is within the defined limits.
