3.5.6 Encoder profile-specific parameters
Index/
Su b index
Description
Access
6)
Data type
Data values
61,000
Name of the station (of the encoder)
R
OCTET STRING [240]
61,001
IP address of the station (of the
encoder)
R
UINT-32
61,002
MAC address of the station (of the
encoder)
R
OCTET STRING [6]
61,003
Default gateway of the station (of the
encoder)
R
UINT-32
61,004
Subnet mask of the station (of the
encoder)
R
UINT-32
65,000
Preset value (can be saved in the
EEPROM with the aid of parameter 971,
see Table 33 on page 31)
R/W
UINT-32
65,001
Operating status
R
Array [0 … 11] UINT-32
.0
Structure header
00.0B.01.01h
0B = 11 entries
.1
Operating status
See Table 36 on page 37
.2
Current errors
See Table 47 on page 60
.3
Supported error messages
See Table 48 on page 60
.4
Current warnings
See Table 49 on page 61
.5
Supported warnings
See Table 50 on page 61
.6
Version of the encoder profile
00.00.04.01h
.7
Operating time (value × 0.1 h)
1 … 00.00.00.00h
.8
Offset value (saved in EEPROM)
1 … 00.00.00.00h
.9
CPR
Resolution per revolution
1 … 00.04.00.00h
1 … 262,144
.10
CMR
Total resolution
1 … 40.00.00.00h
1 … 1,073,741,824
.11
Speed measuring unit
0 = steps/s
1 = steps/100 ms
2 = steps/10 ms
3 = rpm
Table 35: Encoder profile-specific parameters
6
)
R = Read access, W = Write access.
