5 TROUBLESHOOTING
60
OPERATING INSTRUCTIONS | AFS60/AFM60 PROFINET 8015078/145N/2019-05-24 | SICK STEGMANN
Subject to change without notice
5.4.2 Error messages on encoder profile specific parameters
The status of the encoder can be read via the parameter 65,001. The individual bits in
the subindex indicate the nature of the error (see Table 47 to Table 50).
Subindex .2 – Current errors
Bit
Designation
Data values
31 … 6
Reserved
–
5
Memory error
0 = Not active
1 = Active
4
Diagnostics during commissioning
0 = Not active
1 = Active
3
Reserved
–
2
Overvoltage
0 = Not active
1 = Active
1
Undervoltage
0 = Not active
1 = Active
0
Position error
0 = Not active
1 = Active
Table 47: Subindex .2 – Current errors
Subindex .3 – Supported error messages
Bit
Designation
Data values
31 … 6
Reserved
–
5
Memory error
1 = Supported
4
Diagnostics during commissioning
1 = Supported
3
Short-circuit
0 = Not supported
2
Overvoltage
1 = Supported
1
Undervoltage
1 = Supported
0
Position error
1 = Supported
Table 48: Subindex .3 – Supported error messages
