Function of the cams
44 ATM60-Cxx 03/2007
Illustration of the functionality of the cams
Polarity = 0
Cam active
Cam inactive
Position
Lower Upper
limit limit
Polarity = 1
Cam inactive
Cam active
Position
Lower Upper
limit limit
Function of the hysteresis
Position
Lower Upper
limit limit
In work
In Arbeit
