Scope of supply
58 ATM60-Cxx 03/2007
15. Scope of supply
ATM60-Cxx without cable or mating connector.
Floppy disk with the EDS file. This file contains device-specific features of the ATM60-Cxx and can be read
by a configuration tool.
Commissioning instructions for ATM60-Cxx.
Note
Further literature
:
CANopen - Communications profile DS 301 V 4.0
CANopen - Device profile DS 406 V 2.0, profile for encoders
Addresses
:
CAN in Automation (CiA)
Am Weichselgarten 26
D 91058 Erlangen
Tel.: (49) 9131 - 6 90 86-0
Fax: (49) 9131 - 6 90 86-79
Web: http://www.can-cia.de
16. Ordering information
Encoder without bus connector
Ordering designation Explanation
ATM60-C4H13X13 (Item n°1030024)
Face mount flange (shaft Æ 10 mm)
ATM60-C1H13X13 (Item n°1030025)
Servo flange (shaft Æ 6 mm)
ATM60-CAH13X13 (Item n°1030026) Blind hollow shaft (different Ø via inserts)
Shaft inserts for hollow shaft
The shaft inserts for the blind hollow shaft must be specified separately in the order. The following diameters
are available:
6 mm, ¼”, 8 mm, 3/8”, 10 mm, 12 mm, ½”, 15 mm (no shaft insert necessary)
Bus connector
Ordering designation Explanation
AD-ATM60-SR1CO (Item n°2021686) Radial, with 1x M12 (5-pin), pin
AD-ATM60-SR2CO (Item n°2020935) Radial, with 2x M12 (5-pin), pin, socket
AD-ATM60-KR1CO (Item n°2029230) Radial, cable outlet with 1 PG
AD-ATM60-KR2CO (Item n°2029231) Radial, cable outlet with 2 PG
AD-ATM60-KR3CO (Item n°2029232) Radial, cable outlet with 3 PG
In work
In Arbeit
