Installation
Figure 12 Terminal assignment for use in safe areas
Terminal box
Power supply Field connections (10-pole terminal block)
PA
PA
Terminals 2 and PE are bridged internally, i.e. there is no insulation between
PE and negative potential (see
→ Figure 11).
