FLOWSIC600 · Operating Instructions · 8010458 V 2.0 · © SICK MAIHAK GmbH 55
Commissioning
4.6
Function Test
The major system parameters are configured at the factory. The default settings should
allow error free operation of the FLOWSIC600. Nevertheless, correct meter operation
should be verified on site when the meter is installed and is subject to actual operating
conditions.
4.6.1 Function test on FLOWSIC600 with LCD front panel
The FLOWSIC600 is functioning correctly, if the standard display shows two pages of
measurands and current readings and the pages alternate every 5 seconds.
If a current error or warning is active, the display will be interrupted by an error message
every 2 seconds. As soon as the cause of the error/warning has been rectified, the
FLOWSIC600 automatically returns to the standard display.
If the logbooks contain unacknowledged Errors, Warnings or Information, the
corresponding letter is displayed in the upper right hand corner and flashes. The letter
stops flashing, once the message has been acknowledged in the logbook.It disappears
when the entries have been cleared from the logbook.
Detailed information on errors is available in the logbook (see
→
pg.68, 5.4.1 and
→
pg.86,
7.2 of this Manual). See chapter
→
»Troubleshooting« .
4.6.2 Function test on FLOWSIC600 with LED front panel
The FLOWSIC600 is functioning correctly when the green status LEDs for each measuring
path installed start flashing periodically approximately 30 seconds after the power supply
is switched on.
If the yellow LED flashes, the FLOWSIC600 works in the operation state ’’Check request’’
with an insignificantly reduced accuracy (e.g. if one path fails).
If the yellow LED lights up permanently, the measurement is invalid. In this case, you must
diagnose the error (see Chapter 8 of this Manual).
You are advised to check the plausibility of the measured and diagnosis
values, even if the device is functioning properly (see chapter
→
»Maintenance«).
