8012704/YHS4/V2-0/2016-10 | SICKOPERATING INSTRUCTIONS | GM32
Subject to change without notice
5 OPERATION
5.2.5.1 Diagnosis
The “Diagnosis” menu shows the current error messages.
Status messages, status indicators and system states
The GM32 creates a logbook.
▸ Access to the logbook is performed exclusively via SOPAS ET,
see “SOPAS ET (PC program)”, page 10.
The GM32 signals a malfunction or an unsafe operational state with status signals
(option) (→ electrical connection diagram).
List of error messages and measures for clearing malfunctions
see “Error messages”, page 56
Status Status indicators
(LED)
Significance Measured
value dis-
play
Analog
outputs
[1]
Status sig-
nal
[2],[3]
Power On
Green
Power supply in order --- --- ---
Uncertain
Green, however, mea-
sured value blinks
Measured value uncertain (e.g. outside cali-
bration range)
Cause: Press the DIAG button
All messages → SOPAS ET Logbook.
Clearing malfunctions, see “Error messages”,
page 56.
Current Current According to
setting
Mainte-
nance
request
Yellow
Irregularities (e.g. gas temperature too high,
deviation from check cycle too high) that
require a review of the cause.
The measured values are valid.
Cause: Press the DIAG button
All messages → SOPAS ET Logbook.
Clearing malfunctions, see “Error messages”,
page 56.
Current Current According to
setting
Failure
Red
Device failure (e.g. lamp failed)
Cause: Press the DIAG button
All messages → SOPAS ET Logbook.
Clearing malfunctions, see “Error messages”,
page 56.
Last valid
measured
value held
Last valid
measured
value held
According to
setting
Table 9: Status messages, status indicators and system states
[1] Option
[2] Option. Refer to the delivered System Documentation for the assignment of the status outputs.
[3] See SOPAS ET in the “Digital outputs” menu.
