9 TECHNICAL DATA
9.3.7 Bitmap Table Function “Check” and “Out of Specification”
The “Function Check” and “Out of Specification” is currently not defined
9.3.8 Bitmap Table “Extended”
Additional functions, such as alarm functions are listed in Bitmap Table.
9.3.9 Table “Operating States”
Bit No. Name Comment
0 -31 not specified Bit=1: active
Table 31: Bitmap Table for “Function Check” and “Out of Specification”
Bit No. Name Comment
0 Alarm purge air Bit=1: active
1 Alarm optic housing temperature Bit=1: active;
2 Alarm lamp current Bit=1: active;
3 Alarm lamp integration Bit=1: active;
4 Alarm pressure (pressure < 800 hPa or pressure > 1300 hPa) Bit=1: active
5-31 Reserved
Table 32: Bitmap Table for extended functions
Value Operating state
0 not defined
1 Initialisation
2 Measuring
3 Maintenance
4 RCycle
5 Check cycle
6 ZeroAdjust
7 Alignment
8 Boxmeasuring
9 Restart
10 Reserved
11 Reserved
12 Reserved
13 Reserved
14 Reserved
15 Reserved
16 Reserved
17 Reserved
18 Reserved
19 Reserved
20 Reserved
Table 33: Table “Operating states”
